High-Temperature Resistance Of Cr10Ni90 Nichrome Alloy Wire For Industrial Furnaces And Heaters

Introduction:

Cr10Ni90 nickel-chromium alloy wire is a high-performance resistance heating material, mainly composed of 90% nickel and 10% chromium, with excellent high-temperature strength, oxidation resistance and corrosion resistance. The maximum operating temperature of this alloy wire can reach 1300℃, the melting point is about 1400℃, the density is 8.7 g/cm³, and the resistivity is 1.09±0.05 μΩ·m at 20℃. Its good ductility and welding properties make it easy to process into heating elements of different shapes. Cr10Ni90 alloy wire is widely used in industrial furnaces, heaters and other high-temperature equipment, especially suitable for use in high temperature and corrosive environments.

Applications:

1. Electric heating elements: widely used in the manufacture of electric heating wires, electric heating rods, etc., and applied to heating equipment such as electric kettles, ovens, and industrial furnaces.
2. Industrial heating equipment: used for high-temperature heaters, heat treatment equipment, etc. in the chemical and petroleum industries.
3. Resistor elements in corrosion-resistant environments: suitable for heating equipment under complex conditions such as seawater and acidic environments.
4. Electronic and electrical fields: used to manufacture components such as resistors and potentiometers.
5. Thermocouple materials: can be used for temperature measurement and control equipment.

Technical Parameters:

---

Performance material		Cr10Ni90	Cr20Ni80	Cr30Ni70	Cr15Ni60	Cr20Ni35	Cr20Ni30
Composición	Ni	90	Rest	Rest	55.0～61.0	34.0～37.0	30.0～34.0
	Cr	10	20.0～23.0	28.0～31.0	15.0～18.0	18.0～21.0	18.0～21.0
	Fe	－	≤1.0	≤1.0	Rest	Rest	Rest
Temperatura máxima℃		1300	1200	1250	1150	1100	1100
Punto de fusion ℃		1400	1400	1380	1390	1390	1390
Densidad g/cm3		8.7	8.4	8.1	8.2	7.9	7.9
Resistividad μΩ·m,20℃		0.76±0.05	1.09±0.05	1.18±0.05	1.12±0.05	1.00±0.05	1.04±0.05
Alargamiento a la ruptura		≥20	≥20	≥20	≥20	≥20	≥20
Calor especifico J/g.℃		－	0.44	0.461	0.494	0.5	0.5
Conductividad térmica KJ/m.h℃		－	60.3	45.2	45.2	43.8	43.8
Coeficiente de expansión de líneas a×10-6/(20～1000℃)		－	18	17	17	19	19
Estructura micrográfica		－	Austenite	Austenite	Austenite	Austenite	Austenite
Propiedades magnéticas		－	Nonmagnetic	Nonmagnetic	Nonmagnetic	Weak magnetic	Weak magnetic

Form	Specification
Wire	Diameter=0.025mm~8mm
Flat wire	Width=0.40~6.0mm	Thick=0.03~0.50mm
Strip	width=8~250mm	Thick=0.05~3.0mm
Bar	Diameter=8~100mm	Long=50~1000

Service:

---

By choosing our NiCr alloy heaters, you gain access to a heating solution that combines efficiency, reliability, and flexibility. We are committed to delivering top-quality products and services that enhance your production efficiency and reduce energy consumption. With our heaters, you can expect outstanding performance and a customized approach to meet your heating needs.

contact us

email:victory@dlx-alloy.com

Oem service:
Welcome customized size
We are experience factory for OEM&ODM service

Size dimension range:

---

Wire: 0.01-10mm

Ribbons: 0.05*0.2-2.0*6.0mm

Strip: 0.05*5.0-5.0*250mm

NiCr series: Cr20Ni80, Cr30Ni70, Cr15Ni60, Cr20Ni35, Cr20Ni30

Packing and Shipping:

---

Sturdy cardboard boxes are used for packaging NiCr Alloy.

Each box has dimensions of approximately 26 cm (length) x 26 cm (width) x 30 cm (height).

The shipping method for NiCr Alloy depends on the customer's requirements.
