Brand Name : | Victory |
Model Number : | Inconel 600 |
Certification : | ISO9001 ROHS |
Price : | Negotiable |
Payment Terms : | L/C, T/T, Western Union, MoneyGram |
Supply Ability : | 300 tons per month |
Delivery Time : | 20~40 Days |
Inconel 600 alloy material performance?
Inconel 600 is a nickel-based alloy with the following characteristics:
Excellent corrosion resistance, able to resist corrosion in a variety of highly corrosive environments.
Superb oxidation resistance at high temperatures, able to be used for long periods at temperatures above 800°C.
Relatively high strength and hardness, allowing use under high stress conditions.
Good weldability, making it convenient for fabrication through welding.
How does the maximum operating temperature of Inconel 600 compare to other high-temperature alloys?
Inconel 600 has an excellent high-temperature performance compared to many other high-temperature alloys. Here's a comparison of the maximum operating temperatures:
Inconel 600:
Maximum long-term operating temperature: Around 1100°C (2012°F)
Maximum short-term operating temperature: Around 1200°C (2192°F)
Other high-temperature alloys:
Stainless Steel 304: Maximum around 800-900°C (1472-1652°F)
Stainless Steel 310: Maximum around 1100°C (2012°F)
Hastelloy C-276: Maximum around 1100°C (2012°F)
Haynes 230: Maximum around 1150°C (2102°F)
Inconel 718: Maximum around 650-800°C (1202-1472°F)
Compared to the other alloys listed, Inconel 600 has one of the
highest maximum operating temperatures, making it well-suited for
the most demanding high-temperature applications.
What are the typical operating temperature ranges for Inconel 600 components?
Cryogenic temperatures down to around -250°C (-418°F)
Up to around 1100°C (2012°F) for long-term use
Up to around 1200°C (2192°F) for short-term use
The excellent high-temperature strength and oxidation resistance of
Inconel 600 allows it to be used in a wide range of
high-temperature applications, such as:
Components in nuclear reactors
Furnace parts
Combustion equipment
Aerospace applications
Chemical processing equipment
what's the main application of Inconel 600 strip?
Inconel 600 strips are mainly used in the following areas:
Chemical equipment manufacturing
Power equipment manufacturing
Aerospace industry
Nuclear power equipment manufacturing
Medical device manufacturing
Chemical Properties of Inconel 600
C | Cr | Ni+Co | Al | Ti | Fe | Nb+Ta | Mn | Si | P | S | Cu |
≤0.15 | 14.0~17.0 | ≥72 | ≤0.35 | ≤0.50 | 6.0~10.0 | ≤1.0 | ≤1.0 | ≤0.5 | ≤0.04 | ≤0.015 | ≤0.5 |
ITEM | θ/℃ | TENSIE STRENGTH | HBS | |||
σb/MPa | σP0.2/MPa | δ5/% | φ/% | |||
BAR/ROD | 20 | ≥585 | ≥240 | ≥30 | - | 134~217 |
RING | 20 | ≥520 | ≥205 | ≥35 | - | ≥187 |
HOT ROLL PLATE | 20 | ≥550 | ≥240 | ≥35 | ≥40 | - |
900 | ≥95 | ≥45 | ≥40 | ≥50 | - | |
COLD ROLLED SHEET | 20 | ≥550 | ≥240 | ≥30 | - | - |
900 | ≥90 | ≥40 | ≥60 | - | - | |
COLD ROLLED SHEET | 20 | ≥550 | ≥200 | ≥30 | - | - |
STRIP | 20 | ≥550 | ≥240 | ≥30 | - | - |
WIRE | 20 | - | HV≤151 |
Shape | Size(mm) |
WIre | 0.5-7.5 |
Rod/Bar | 8.0-200 |
Strip | (0.5-2.5)*(5-180) |
Tube | custom made |
Plate | custom made |
