Tensile 1300~1500 Mpa Nickel Based Alloy ASTM B166 Inconel 600 Spring Wire

Ask Lasest Price
Brand Name :	Victory
Model Number :	Inconel 600
Certification :	ISO9001 ROHS
Price :	Negotiable
Payment Terms :	L/C, T/T, Western Union, MoneyGram
Supply Ability :	300 tons per month
Delivery Time :	20~40 Days

Add to Cart

Product Details
Company Profile

Tensile 1300~1500 Mpa Nickel Based Alloy ASTM B166 Inconel 600 Spring Wire

Inconel 600 wire for spring

Properties of Inconel 600 Relevant for Spring Applications:

High Strength-to-Weight Ratio:
Inconel 600 has a tensile strength of 585-745 MPa, allowing for compact, lightweight spring designs.
The relatively low density of 8.47 g/cm³ helps minimize the weight of Inconel 600 springs.

Excellent Fatigue Resistance:
The microstructural stability of Inconel 600 gives it outstanding fatigue life, withstanding millions of cycles.
This is crucial for springs that undergo repeated flexing and loading.

Corrosion Resistance:
Inconel 600's high chromium content (14-17%) provides excellent resistance to corrosion and oxidation.
This makes Inconel 600 springs suitable for harsh, corrosive environments.

High-Temperature Capability:
Inconel 600 retains its strength and elasticity at temperatures up to 1100°C.
This allows its use in high-heat applications like engine valves and furnace components.

Recommend other nickel-based alloys that are commonly used for spring manufacturing

Inconel 718:
Another nickel-chromium superalloy, similar to Inconel 600 but with higher strength.
Commonly used for aerospace engine springs, fasteners, and other high-strength applications.

Hastelloy C-276:
A nickel-molybdenum-chromium alloy with excellent corrosion resistance.
Often used for chemical processing equipment springs and other corrosive environment applications.

Nimonic 90:
A nickel-chromium-cobalt-titanium alloy with high-temperature strength and creep resistance.
Ideal for valve springs and other engine components operating at elevated temperatures.

MP35N:
A nickel-cobalt-chromium-molybdenum alloy with extremely high strength and fatigue life.
Commonly used for medical device springs, aerospace, and other highly demanding applications.

Parameter:

Chemical Properties of Inconel 600

C	Cr	Ni+Co	Al	Ti	Fe	Nb+Ta	Mn	Si	P	S	Cu
≤0.15	14.0～17.0	≥72	≤0.35	≤0.50	6.0～10.0	≤1.0	≤1.0	≤0.5	≤0.04	≤0.015	≤0.5

ITEM	θ/℃	TENSIE STRENGTH				HBS
ITEM	θ/℃	σb/MPa	σP0.2/MPa	δ5/%	φ/%	HBS
BAR/ROD	20	≥585	≥240	≥30	-	134～217
RING	20	≥520	≥205	≥35	-	≥187
HOT ROLL PLATE	20	≥550	≥240	≥35	≥40	-
HOT ROLL PLATE	900	≥95	≥45	≥40	≥50	-
COLD ROLLED SHEET	20	≥550	≥240	≥30	-	-
COLD ROLLED SHEET	900	≥90	≥40	≥60	-	-
COLD ROLLED SHEET	20	≥550	≥200	≥30	-	-
STRIP	20	≥550	≥240	≥30	-	-
WIRE	20				-	HV≤151

Shape	Size(mm)
WIre	0.5-7.5
Rod/Bar	8.0-200
Strip	(0.5-2.5)*(5-180)
Tube	custom made
Plate	custom made

contact us

email:victory@dlx-alloy.com

Oem service:
Welcome customized size
We are experience factory for OEM&ODM service

Tensile 1300~1500 Mpa Nickel Based Alloy ASTM B166 Inconel 600 Spring Wire
