Introduction:
Inconel 601 pipe is a pipe commonly used in the chemical industry.
It is composed of materials such as nickel (Ni), chromium (Cr),
iron (Fe) and aluminum (Al), with a minimum content of 58%, a
density of 8.1 g/cubic centimeter, and a melting point of 1360
degrees Celsius. The pipe has a tensile strength of 650 MPa, an
elongation of 30% and a yield strength of 300 MPa. The specific
heat capacity is 477 Joules/kg-C.
Inconel 601 pipe is widely used in chemical equipment, corrosive
media treatment and high temperature reactors. It has excellent
corrosion resistance and high temperature stability, and can
withstand corrosive media, high temperature and high pressure
conditions in chemical processes. Whether in the piping system of
chemical equipment or in installations handling corrosive liquids
or gases, Inconel 601 pipe provides reliable performance, ensuring
safe operation and long-term use of equipment.
The unique properties of this pipe make it one of the ideal choices
for the chemical industry. In various chemical processes, Inconel
601 pipe can effectively resist corrosion and oxidation while
maintaining good mechanical strength and heat resistance. It plays
an important role in handling corrosive media, high-temperature
reactors and other chemical processes, providing reliable solutions
for chemical companies.
Characteristic:
- Corrosion resistance: Inconel 601 pipe has excellent corrosion
resistance and can resist a variety of corrosive media, including
acidic, alkaline and oxidizing media. It has good corrosion
resistance to common chemicals such as sulfuric acid, hydrochloric
acid, nitric acid, and hydrofluoric acid.
- High temperature stability: The alloy has excellent high
temperature stability and can maintain good structural integrity
and mechanical properties in high temperature environments. In the
chemical industry, which often faces high-temperature corrosive
conditions, Inconel 601 pipe provides reliable performance.
- Oxidation resistance: Inconel 601 tube has good antioxidant
properties and can reduce the oxidation loss of materials in
high-temperature oxidizing environments.
- Good mechanical properties: The alloy has excellent
high-temperature strength, deformation resistance and fatigue life,
and can withstand high stresses and loads in the chemical industry.
Advantage:
- Corrosion resistance: Inconel 601 pipe has excellent corrosion
resistance in the chemical industry. It can withstand the erosion
of various acidic, alkaline and oxidizing media and is suitable for
chemical equipment and pipeline systems.
- Long life: Due to its corrosion resistance and high temperature
strength, Inconel 601 pipe is able to provide a long service life,
reducing the frequency of equipment repairs and replacements.
- Good workability: The alloy has good workability and can be shaped
and processed through hot and cold working methods to facilitate
the manufacture of pipes and components of various shapes and
sizes.
Application:
- Chemical equipment: Inconel 601 pipe can be used to manufacture
chemical equipment, such as reactors, distillation towers, heat
exchangers, storage tanks, etc. Its excellent corrosion resistance
and high temperature stability enable it to withstand corrosive
media and high temperature environments in the chemical industry.
- Chemical transfer pipes: This alloy is suitable for piping systems
in the chemical industry to transport various chemicals and
solvents. Its anti-corrosion properties ensure the reliability and
safety of pipelines.
- Catalyst Reactor: Inconel 601 tube can be used to manufacture
catalytic reactors for various chemical reaction processes. Its
high temperature stability and corrosion resistance enable it to
adapt to complex reaction environments.
Other relevant knowledge points:
Inconel 601 is a nickel-chromium-iron-based alloy that contains
aluminum and other elements to improve its oxidation resistance and
high-temperature strength.
The alloy can further enhance its properties through heat treatment
methods, such as solution treatment and aging treatment, to achieve
higher strength and corrosion resistance.
In addition to the chemical industry, Inconel 601 is also widely
used in petrochemical, electric power, nuclear industry and other
fields, especially in equipment manufacturing and chemical reaction
processes in high temperature and corrosive environments.
Parameter:
Chemical Properties of Inconel 601
| Nickel | Chromium | Iron | Aluminum | Carbon | Manganese | Sulfur | Silicon | Copper |
| 58%-63% | 21%-25% | Remainder | 1%-1.7% | 0.10% max | 1% max | 0.015% max | 0.50% max | 1% max |
Type we could offer
| AMS Number | Alloy | Type | UNS | Misc./Shape |
|---|
| AMS 5715 | Inconel 601 | Nickel | N06601 | |
| AMS 5715 Bar | Inconel 601 | Nickel | N06601 | Bar |
| AMS 5715 Custom Tube | Inconel 601 | Nickel | N06601 | Custom Tube |
| AMS 5715 Forging | Inconel 601 | Nickel | N06601 | Forging |
| AMS 5715 Ring | Inconel 601 | Nickel | N06601 | Ring |
| AMS 5870 | Inconel 601 | Nickel | N06601 | |
| AMS 5870 Plate | Inconel 601 | Nickel | N06601 | Plate |
| AMS 5870 Sheet | Inconel 601 | Nickel | N06601 | Sheet |
| AMS 5870 Strip | Inconel 601 | Nickel | N06601 | Strip |
contact us
email:victory@dlx-alloy.com
Oem service:
Welcome customized size
We are experience factory for OEM&ODM service
Q & A:
Q: Can Inconel 601 tubes withstand high-temperature environments?
A: Yes, Inconel 601 tubes are specifically designed to withstand
high-temperature environments. They exhibit excellent
high-temperature strength and oxidation resistance, making them
suitable for applications in heat-treating equipment, furnaces, and
exhaust systems where extreme temperatures are present.
Q: Are Inconel 601 tubes resistant to corrosion?
A: Yes, Inconel 601 tubes offer good resistance to corrosion,
particularly oxidation. They withstand high-temperature corrosion,
including carburization and nitridation, making them suitable for
use in petrochemical processing, thermal processing, and power
generation industries where corrosive environments are present.
