Introduction:
Incoloy 825 Wire is an alloy wire composed of elements such as
nickel, iron, chromium and molybdenum. This alloy wire is suitable
for applications such as culture tanks, centrifuges and biosensors.
Key parameters include a nickel content between 38-46% and a
density of 8.14 g/cm3. Its linear expansion coefficient is 14.0
μm/m·C (in the range of 20-100 °C), its stiffness modulus is 75.9
kN/mm2, and its elastic modulus is 196 kN/mm2. In addition, the
alloy wire has an elongation of more than 30%, a tensile strength
of 550 MPa, and a yield strength of 220 MPa.
Incoloy 825 Wire is widely used in applications such as culture
tanks, centrifuges and biosensors. It has excellent corrosion
resistance and high temperature stability, and can withstand
chemical environments and high temperature conditions. The alloy
wire can be used to manufacture corrosion-resistant containers,
centrifuge parts, electrodes and connecting wires for biosensors,
etc., providing reliable material solutions for the fields of
bioprocessing and life sciences.
To sum up, Incoloy 825 Wire is an alloy wire widely used in culture
tanks, centrifuges, biosensors and other fields. With its excellent
physical and mechanical properties, as well as corrosion resistance
and high temperature stability, it can meet the needs of
bioprocessing and life science fields and provide reliable material
support for related applications.
Parameter:
Chemical Composition (%) |
C | Si | Mn | S | Mo | Ti | Cr | Ni | Fe | Cu |
≤0.05 | ≤0.50 | ≤1.00 | ≤0.03 | ≤2.5~3.5 | ≤0.6~1.2 | 19.5~23.5 | 38.0~46.0 | ≥22.0 | 1.5~3.0 |
Standard |
Sheet/Plate | Round bar/Wire | Pipe | Tube |
ASME SB-424 ASME SB-906 | ASME SB-425 | ASME SB-423 ASME SB-829 ASME SB-163 ASME SB-751 ASME SB-775 | ASME SB-704
ASME SB-705
ASME SB-751
ASME SB-775 |
Mechanical Properties |
Status | Tensile Strength (Rm N/mm2) | Yield strength (RP0.2N/mm2) | Elongation(A5%) | HB |
Solution treatment | 550 | 220 | 30 | ≤200 |
Incoloy 825 (NS142) similiaer trademark |
UNS | Trademark | JIS | W.Nr |
N08825 | Incoloy825 | NCF825 | 2.4858 |
 | | Shape | Size(mm) | | Wire | 0.5-7.5 | | Rod/Bar | 8.0-200 | | Strip | (0.5-2.5)*(5-180) | | Tube | custom made | | Plate | custom made |
|
Characteristic:
- Corrosion resistance: Incoloy 825 alloy wire exhibits excellent
corrosion resistance and can resist corrosion of biological fluids,
chemicals and oxidizing media on bioengineering equipment.
- Biocompatibility: This alloy wire has good biocompatibility, is
non-toxic and non-irritating to biological tissues, and will not
cause allergies or rejection reactions.
- Temperature stability: Incoloy 825 alloy wire has good
high-temperature stability and can withstand the stress and
pressure in high-temperature environments during bioengineering
processes.
- Strength and hardness: Incoloy 825 alloy wire has high strength and
hardness and is suitable for manufacturing mechanical components in
bioengineering equipment.
Advantage:
- Corrosion resistance: Incoloy 825 alloy wire has excellent
corrosion resistance in bioengineering, which can extend the
service life of equipment and improve its stability and
reliability.
- Biocompatibility: This alloy wire has good biocompatibility, which
can reduce adverse effects on organisms and make bioengineering
equipment safer and more reliable.
- Temperature adaptability: Incoloy 825 alloy wire is able to
maintain its performance over a wide temperature range and is
suitable for different temperature conditions in bioengineering
processes.
- Excellent mechanical properties: Incoloy 825 alloy wire has good
strength and hardness and can withstand the mechanical stress and
pressure in bioengineering equipment, improving the reliability of
the equipment.
Specific applications:
- Bioreactors and culture tanks: Incoloy 825 alloy wire can be used
to manufacture equipment such as bioreactors and culture tanks to
resist corrosion of equipment by biological fluids and chemicals,
and ensure the stability and controllability of the bioengineering
process.
- Mass Transfer Equipment: Suitable for manufacturing mass transfer
equipment such as membrane separators and centrifuges to provide
corrosion resistance and temperature stability.
- Biosensors and Probes: Can be used to manufacture biosensors and
probes for the detection and monitoring of biomolecules and
chemicals in bioengineering processes.
Other relevant knowledge points:
Cleaning and Disinfection: In bioengineering equipment manufactured
with Incoloy 825 alloy wire, proper cleaning and disinfection
procedures are crucial to ensure their hygiene and safety.
Standards and specifications: During the manufacturing process of
bioengineering equipment, follow applicable standards and
specifications, such as cGMP (Good Manufacturing Practice), etc.,
to ensure product quality and compliance.
contact us
email:victory@dlx-alloy.com
Oem service:
Welcome customized size
We are experience factory for OEM&ODM service
Q & A:
Q: Can Incoloy 825 Wire be customized to specific requirements?
A: Yes, Incoloy 825 Wire can be customized to meet specific
requirements. This includes customization of wire diameter, length,
surface finish, and even the production of custom wire profiles or
shapes to suit the unique needs of different applications.
Q: What is the lead time for customizing Incoloy 825 Wire?
A: The lead time for customizing Incoloy 825 Wire may vary
depending on the specific customization requirements and the order
volume. It is recommended to contact the manufacturer or supplier
to discuss the customization details and obtain an accurate
estimate of the lead time.
