    Heat Resistant Supermalloy Rod ASTM B166 Nickel Alloy 600 Round Bar 75mm 80mm 90mm

    Ask Lasest Price
    Brand Name : Victory
    Model Number : Inconel 600
    Certification : ISO9001 ROHS
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 300 tons per month
    Delivery Time : 20~40 Days
    • Product Details
    • Company Profile

    Heat Resistant Supermalloy Rod ASTM B166 Nickel Alloy 600 Round Bar 75mm 80mm 90mm

    Inconel series include codes?


    Inconel 600

    Chemical composition: Ni 72%, Cr 14-17%, Fe 6-10%
    Widely used in high-temperature corrosive environments such as chemical industry and power generation
    Inconel 601

    Chemical composition: Ni 60-63%, Cr 23-25%, Al 1.0-1.7%
    Has excellent high temperature strength and corrosion resistance
    Inconel 617

    Chemical composition: Ni 44-46%, Cr 20-24%, Co 10-15%, Mo 8-10%
    High temperature strength, still good strength above 1100°C
    Inconel 625

    Chemical composition: Ni 58%, Cr 20-23%, Mo 8-10%, Nb 3.15-4.15%
    Excellent corrosion resistance and high temperature mechanical properties
    Inconel 718

    Chemical composition: Ni 50-55%, Cr 17-21%, Fe bal., Nb+Ta 4.75-5.5%
    High temperature resistance and strength, widely used in aerospace engines, etc.
    Inconel 725

    Chemical composition: Ni 58%, Cr 20-23%, Mo 8-10%, Nb 3.15-4.15%
    Similar to Inconel 625, but slightly less strong

    Difference from Inconel 625 and Inconel 600?


    Chemical composition:

    Inconel 625 contains higher niobium (Nb) and molybdenum (Mo) contents, 3.15-4.15% and 8-10% respectively. Inconel 600, on the other hand, contains only very small amounts of Nb and Mo.
    Inconel 625 contains a lower chromium (Cr) content of 20-23%, while Inconel 600 has 14-17%.
    Performance features:

    Inconel 625 has better corrosion resistance, especially in seawater, acidic and oxidizing environments.
    Inconel 625 has higher strength and hardness and can maintain good strength at high temperatures.
    Inconel 625 has better resistance to stress corrosion cracking.
    Application areas:

    Inconel 625 is widely used in marine, chemical, military and other applications requiring high corrosion resistance.
    Inconel 600 is more used in conventional high-temperature environments, such as power plants, petrochemical equipment, etc.


    what's the production process of inconel 600 round bar?


    Smelting:

    An electric arc furnace or induction furnace is used to smelt nickel, chromium, iron and other raw materials to produce Inconel 600 alloy melt.
    Casting:

    Inject the molten Inconel 600 alloy into a water-cooled metal mold for continuous casting or sand casting to obtain a rough casting.
    forging:

    The rough casting is heated to the plastic temperature and then forged or extruded to obtain a prefabricated billet.
    Hot rolled:

    The prefabricated billet is heated to a specified temperature and then rolled repeatedly through a hot rolling mill until a round steel bar of the required diameter is obtained.
    annealing:

    The rolled round steel bars are annealed to improve their plasticity and corrosion resistance.
    Inspection and surface treatment:

    The rolled and annealed Inconel 600 round steel bars were tested for size, chemical composition, mechanical properties, etc.
    Surfaces are polished, pickled or otherwise treated as required to meet the end product's usage requirements.


    what's the main application of Inconel 600 round bar?


    Chemical industry:

    Used to manufacture various chemical reactors, storage tanks, pipelines and other equipment, with excellent corrosion resistance.
    It is widely used in corrosive environments in petrochemical, pharmaceutical, pulp and other industries.
    Power generation industry:

    As parts and materials for steam turbines, generators and heat exchange equipment, such as turbine blades, bearings, seals, etc.
    It has good strength and corrosion resistance in high temperature and high pressure environments.
    Aerospace field:

    Special components used in the manufacture of aircraft engine parts, missiles and spacecraft.
    Materials are required to have excellent corrosion resistance, high temperature resistance and other properties.


    Parameter:

    Chemical Properties of Inconel 600


    CCrNi+CoAlTiFeNb+TaMnSiPSCu
    ≤0.1514.0~17.0≥72≤0.35≤0.506.0~10.0≤1.0≤1.0≤0.5≤0.04≤0.015≤0.5

    ITEMθ/℃TENSIE STRENGTHHBS
    σb/MPaσP0.2/MPaδ5/%φ/%
    BAR/ROD20≥585≥240≥30-134~217
    RING20≥520≥205≥35-≥187
    HOT ROLL PLATE20≥550≥240≥35≥40-
    900≥95≥45≥40≥50-
    COLD ROLLED SHEET20≥550≥240≥30--
    900≥90≥40≥60--
    COLD ROLLED SHEET20≥550≥200≥30--
    STRIP20≥550≥240≥30--
    WIRE20-HV≤151

    Shape
    Size(mm)
    WIre
    0.5-7.5
    Rod/Bar
    8.0-200
    Strip
    (0.5-2.5)*(5-180)
    Tube
    custom made
    Plate
    custom made

    contact us

    email:victory@dlx-alloy.com

    Oem service:
    Welcome customized size
    We are experience factory for OEM&ODM service
