Ernicu-7 Nickel MIG/TIG Monel 400 K500 Welding Wire 1.2mm 1.6mm 2.0mm 2.4mm 3.2mm

Ask Lasest Price
Brand Name :	Victory
Model Number :	ERNiCu-7 ERNiCu-1 ERNiCrMo-3,ERNiCrMo-4,ERNiCrMo-13,ERNiCrFe-7,ERNiCr-3
Certification :	CE,ROHS,ISO 9001
Payment Terms :	L/C, T/T, Western Union, MoneyGram
Supply Ability :	300 tons per month
Delivery Time :	5-21 days

Add to Cart

Product Details
Company Profile

Ernicu-7 Nickel MIG/TIG Monel 400 K500 Welding Wire 1.2mm 1.6mm 2.0mm 2.4mm 3.2mm

Ernicu-7 Nickel 1.2mm 1.6mm 2.0mm 2.4mm 3.2mm MIG/TIG Monel 400 Welding Wire

ERNiCu-7

Nickel-copper welding wire ERNiCu-7 Standard: SG-NiCu30MnTi

Applications: - Welding of Monel 400 alloy itself; as well as welding of Monel 400 alloy with steel; - Used for surface cladding of steel.

Copper-nickel welding wire ERCuNi Standard: SG-CuNi30Fe

Applications: - Used for welding of copper-nickel alloys and specific bronze materials themselves, as well as for welding these materials with Monel 400 alloy or Nickel 200.

ENiCu-7 Welding of MONEL 400 alloy itself; as well as welding of MONEL 400 alloy with steel; used for surface cladding of steel.

ERNiCu-7 Welding of MONEL 400 alloy itself, as well as welding of MONEL 400 alloy with steel; surface cladding of steel using the submerged arc welding method; (filler material 61 alloy for the buffer layer needs to be deposited by manual arc welding method)

Chemical Properties

C	Si	Mn	Cr	P	Ni
≤0.01	≤0.2	≤0.5	22.0-24.0	≤0.015	Rem
Al	Mo	Fe	Cu	S	Co
0.10-0.40	15.0-16.50	≤0.5	≤0.1	<0.01	<0.20

Typical Welding Parameters
Diameter		Process	Volt	Amps (flat)	Amps (V/OH)
inch	(mm)	Process	Volt	Amps (flat)	Amps (V/OH)
0.035	0.9	GMAW	26-29	150-190	Spray Transfer 100% Argon
0.045	1.2	GMAW	28-32	180-220	Spray Transfer 100% Argon
1/16	1.6	GMAW	29-33	200-250	Spray Transfer 100% Argon
1/16	1.6	GTAW	14-18	90-130	100% Argon
3/32	2.4	GTAW	15-20	120-175	100% Argon
1/8	3.17	GTAW	15-20	150-220	100% Argon

Tensile Strength	109 Ksi	790 MPA
Yield Strength	68 Ksi	470 MPA
Elongation	40-45%
Density g/cm3	8.60 g/cm3
Melting Point ℃	1300-1360℃
Coefficient of Expansion. 21-93 Co, μm/m * Co	11.90

This is a series of welding wire products including ERNiCrMo-3, ERNiCrMo-4, ERNiCrMo-13, ERNiCrFe-3, ERNiCrFe-7, ERNiCr-3, ERNiCr-7, ERNiCu-7 and ERNi-1.

Nickel welding wire is available in different grades and specifications depending on specific application requirements. Various nickel alloy welding wires (such as ERNiCr-3, ERNiCrMo-3, etc.) and pure nickel welding wires (such as ERNi-1, ERNi-2, etc.) can be selected according to specific alloy composition and performance requirements.

In short, nickel welding wire is an important welding material with excellent welding performance and adaptability. It plays an important role in various industrial fields, providing reliable welding solutions for manufacturing and maintaining high-quality metal structures.

Item	ERNiCrMo-3	ERNiCrMo-4	ERNiCrMo-13	ERNiCrFe-7	ERNiCr-3	ERNiCu-7	ERCuNi	ERNi-1
C	0.1	0.02	0.01	0.04	0.1	0.15	0.03	0.15
Mn	0.05	1	0.5	1	2.5-3.5	4	0.5-1.0	1
Fe	5	4-7	1.5	7-11	3	2.5	0.65	1
P	0.02	0.04	0.015	0.02	0.03	0.02	0.01	0.03
S	0.015	0.03	0.005	0.015	0.015	0.015	0.01	0.015
Si	0.05	0.08	0.1	0.5	0.5	1.25	0.15	0.75
Cu	0.5	0.5	N/A	0.3	0.5	rest	rest	0.25
Ni	≥58	rest	rest	rest	≥67	62-69	30-32	≥93
Co	N/A	2.5	0.3	N/A	N/A	N/A	N/A	N/A
Al	0.4	N/A	0.1-0.4	1.1	N/A	1.25	0.15	1.5
Ti	0.4	N/A	N/A	1	0.75	1.5-3	0.5	2-3.5
Cr	20-23	14.5-16.5	22-24	28.5-31	18.0-22.0	N/A	N/A	N/A
Nb+Ta	3.5-4.15	N/A	1.8-2.5	0.01	2.0-3.0	N/A	N/A	N/A
Mo	8.0-10	15-17	15-16	0.5	N/A	N/A	N/A	N/A
V	N/A	0.35	N/A	N/A	N/A	N/A	N/A	N/A
W	N/A	3.-4.5	N/A	N/A	N/A	N/A	N/A	N/A
Rest	≤0.50	≤0.50	≤0.50	≤0.50	≤0.50	≤0.50	≤0.50	≤0.50
