Cr20Ni80 Wire NiCr Alloy Widely Used In Heat Treating Ceramics
Glass And More
Product Description:
NiCr alloy, including Cr20Ni80, are valued for their excellent heat
generation, oxidation resistance, and high-temperature performance.
These properties make them reliable and efficient heating elements
in heat treating
ceramics and glass applications. Here's how NiCr alloy is used in heat treating ceramics and glass:
1. Electric Kilns and Furnaces: NiCr alloy is commonly employed as
heating elements in electric kilns and furnaces for ceramic and
glass production. The alloys' high melting point and oxidation
resistance enable them to withstand the high temperatures required
for these processes. NiCr heating elements provide controlled and
uniform heating, allowing for the shaping, glazing, and firing of
ceramics and glass materials.
2. Annealing and Tempering: NiCr alloy is utilized in heat
treatment processes like annealing and tempering to enhance the
structural properties of ceramics and glass. These alloys serve as
heating elements to provide the necessary heat for controlled
cooling and annealing cycles. This helps relieve internal stresses
and improve the strength and durability of the materials.
NiCr (nickel-chromium) alloys, including Cr20Ni80 (Nichrome 80/20),
are indeed widely used in heat treating ceramics and glass
applications. These alloys possess excellent electrical resistance
and high-temperature stability, making them suitable for various
heat treatment processes.
Technical Parameters:
| Performance material | Cr10Ni90 | Cr20Ni80 | Cr30Ni70 | Cr15Ni60 | Cr20Ni35 | Cr20Ni30 |
| Composición | Ni | 90 | Rest | Rest | 55.0～61.0 | 34.0～37.0 | 30.0～34.0 |
| Cr | 10 | 20.0～23.0 | 28.0～31.0 | 15.0～18.0 | 18.0～21.0 | 18.0～21.0 |
| Fe | － | ≤1.0 | ≤1.0 | Rest | Rest | Rest |
| Temperatura máxima℃ | 1300 | 1200 | 1250 | 1150 | 1100 | 1100 |
| Punto de fusion ℃ | 1400 | 1400 | 1380 | 1390 | 1390 | 1390 |
| Densidad g/cm3 | 8.7 | 8.4 | 8.1 | 8.2 | 7.9 | 7.9 |
| Resistividad μΩ·m,20℃ | 0.76±0.05 | 1.09±0.05 | 1.18±0.05 | 1.12±0.05 | 1.00±0.05 | 1.04±0.05 |
| Alargamiento a la ruptura | ≥20 | ≥20 | ≥20 | ≥20 | ≥20 | ≥20 |
| Calor especifico J/g.℃ | － | 0.44 | 0.461 | 0.494 | 0.5 | 0.5 |
| Conductividad térmica KJ/m.h℃ | － | 60.3 | 45.2 | 45.2 | 43.8 | 43.8 |
| Coeficiente de expansión de líneas a×10-6/(20～1000℃) | － | 18 | 17 | 17 | 19 | 19 |
| Estructura micrográfica | － | Austenite | Austenite | Austenite | Austenite | Austenite |
| Propiedades magnéticas | － | Nonmagnetic | Nonmagnetic | Nonmagnetic | Weak magnetic | Weak magnetic |
| Form | Specification |
| Wire | Diameter=0.025mm~8mm |
| Flat wire | Width=0.40~6.0mm | Thick=0.03~0.50mm |
| Strip | width=8~250mm | Thick=0.05~3.0mm |
| Bar | Diameter=8~100mm | Long=50~1000 |
contact us
email:victory@dlx-alloy.com
Oem service:
Welcome customized size
We are experience factory for OEM&ODM service
Size dimension range:
Wire: 0.01-10mm
Ribbons: 0.05*0.2-2.0*6.0mm
Strip: 0.05*5.0-5.0*250mm
NiCr series: Cr20Ni80, Cr30Ni70, Cr15Ni60, Cr20Ni35, Cr20Ni30
Packing and Shipping:
NiCr Alloy Packaging and Shipping
NiCr Alloy products are packaged in 25kg/bag paper bags.
The bags are placed on pallets.
The pallets are then wrapped with foam and stretch film.
The wrapped pallets are then loaded into the container.
The container is then sealed and shipped.
FAQ :
What is NiCr alloy?
NiCr alloy is an alloy composed of nickel and chromium that has
high electrical resistance and high temperature stability.
What are the applications of NiCr alloy in heat treatment of
ceramics and glass?
NiCr alloys are commonly used in heat-treating ceramic and glass
applications. It can be used as a heating element for electric
stoves and electric furnaces, providing a controlled heating
process.
What are the advantages of NiCr alloy?
NiCr alloy has excellent resistance properties, high temperature
stability and oxidation resistance, and can provide long-lasting
heating effect in high temperature environments.
What is the melting point of NiCr alloy?
The melting point of NiCr alloy is approximately 1400°C (2550°F),
which allows it to operate at high temperatures without losing
structural integrity.
