Inconel 625 Aws A5.14 Nickel ERNiCrMo-3 Welding Wire Nickel Alloy TIG Weld Wire

Ask Lasest Price
Brand Name :	Victory
Model Number :	ERNiCrMo-3,ERNiCrMo-4,ERNiCrMo-13,ERNiCrFe-7,ERNiCr-3
Certification :	CE,ROHS,ISO 9001
Payment Terms :	L/C, T/T, Western Union, MoneyGram
Supply Ability :	300 tons per month
Delivery Time :	5-21 days

Add to Cart

Product Details
Company Profile

Inconel 625 Aws A5.14 Nickel ERNiCrMo-3 Welding Wire Nickel Alloy TIG Weld Wire

Welding wire is a vital metal material that plays a key role in filling the weld seam and achieving welding connections during the welding process. There are many different types of welding wires available on the market, such as ERNiCrMo-3, ERNiCrFe-7, ERNiCu-7, etc. Each welding wire has a unique chemical composition and welding characteristics.

These welding wires are widely used in welding processes in various industries. They offer outstanding performance advantages such as corrosion resistance, high temperature strength and oxidation resistance to meet the requirements of various industrial needs. By choosing the right welding wire, we can ensure the quality, strength and reliability of our welded joints.

Proper selection of the right welding wire is crucial to achieving high-quality welding. Depending on the type of welding material, welding conditions and specific requirements required, selecting the appropriate welding wire can improve the efficiency and success rate of the welding process and ensure that the quality of the final welded connection meets expectations. Therefore, when undertaking a welding project, careful selection of the appropriate welding wire is an important step in ensuring welding quality and performance.

Chemical Properties

C	Si	Mn	Cr	P	Ni
≤0.01	≤0.2	≤0.5	22.0-24.0	≤0.015	Rem
Al	Mo	Fe	Cu	S	Co
0.10-0.40	15.0-16.50	≤0.5	≤0.1	<0.01	<0.20

Typical Welding Parameters
Diameter		Process	Volt	Amps (flat)	Amps (V/OH)
inch	(mm)	Process	Volt	Amps (flat)	Amps (V/OH)
0.035	0.9	GMAW	26-29	150-190	Spray Transfer 100% Argon
0.045	1.2	GMAW	28-32	180-220	Spray Transfer 100% Argon
1/16	1.6	GMAW	29-33	200-250	Spray Transfer 100% Argon
1/16	1.6	GTAW	14-18	90-130	100% Argon
3/32	2.4	GTAW	15-20	120-175	100% Argon
1/8	3.17	GTAW	15-20	150-220	100% Argon

Tensile Strength	109 Ksi	790 MPA
Yield Strength	68 Ksi	470 MPA
Elongation	40-45%
Density g/cm3	8.60 g/cm3
Melting Point ℃	1300-1360℃
Coefficient of Expansion. 21-93 Co, μm/m * Co	11.90

Item	ERNiCrMo-3	ERNiCrMo-4	ERNiCrMo-13	ERNiCrFe-7	ERNiCr-3	ERNiCu-7	ERCuNi	ERNi-1
C	0.1	0.02	0.01	0.04	0.1	0.15	0.03	0.15
Mn	0.05	1	0.5	1	2.5-3.5	4	0.5-1.0	1
Fe	5	4-7	1.5	7-11	3	2.5	0.65	1
P	0.02	0.04	0.015	0.02	0.03	0.02	0.01	0.03
S	0.015	0.03	0.005	0.015	0.015	0.015	0.01	0.015
Si	0.05	0.08	0.1	0.5	0.5	1.25	0.15	0.75
Cu	0.5	0.5	N/A	0.3	0.5	rest	rest	0.25
Ni	≥58	rest	rest	rest	≥67	62-69	30-32	≥93
Co	N/A	2.5	0.3	N/A	N/A	N/A	N/A	N/A
Al	0.4	N/A	0.1-0.4	1.1	N/A	1.25	0.15	1.5
Ti	0.4	N/A	N/A	1	0.75	1.5-3	0.5	2-3.5
Cr	20-23	14.5-16.5	22-24	28.5-31	18.0-22.0	N/A	N/A	N/A
Nb+Ta	3.5-4.15	N/A	1.8-2.5	0.01	2.0-3.0	N/A	N/A	N/A
Mo	8.0-10	15-17	15-16	0.5	N/A	N/A	N/A	N/A
V	N/A	0.35	N/A	N/A	N/A	N/A	N/A	N/A
W	N/A	3.-4.5	N/A	N/A	N/A	N/A	N/A	N/A
Rest	≤0.50	≤0.50	≤0.50	≤0.50	≤0.50	≤0.50	≤0.50	≤0.50

Inconel 625 Aws A5.14 Nickel ERNiCrMo-3 Welding Wire Nickel Alloy TIG Weld Wire
