Nickel Alloy 625 600 601 Inconel Welding Wire Ernicrmo-3/Ernicr-3

Ask Lasest Price
Brand Name :	Victory
Model Number :	ERNiCrMo-3,ERNiCrMo-4,ERNiCrMo-13,ERNiCrFe-7,ERNiCr-3
Certification :	CE,ROHS,ISO 9001
Payment Terms :	L/C, T/T, Western Union, MoneyGram
Supply Ability :	300 tons per month
Delivery Time :	5-21 days

Add to Cart

Product Details
Company Profile

Nickel Alloy 625 600 601 Inconel Welding Wire Ernicrmo-3/Ernicr-3

Nickel welding wire is a metal welding material used in welding processes, mainly composed of pure nickel or nickel alloy. It has excellent welding characteristics and performance and is widely used in various industrial fields.

Nickel welding wire provides good melting and flow properties during the welding process, allowing it to effectively connect and fill gaps between metal workpieces. It can adapt to different welding methods, such as argon arc welding, TIG welding, MIG welding, etc.

Nickel welding wire can be used to weld different types of metals, including nickel alloys, stainless steel, high-temperature alloys, copper alloys, and more. It is widely used in aerospace, petrochemical, electric power, chemical, nuclear energy and other industries to manufacture, repair and maintain various equipment and components.

Characteristics of nickel welding wire include good corrosion resistance, high temperature stability and excellent mechanical properties. It can resist oxidation, corrosion and high-temperature environment erosion, maintaining the stability and reliability of welded joints. In addition, nickel welding wire also has good workability and is convenient for welding operations and processing.

Chemical Properties

C	Si	Mn	Cr	P	Ni
≤0.01	≤0.2	≤0.5	22.0-24.0	≤0.015	Rem
Al	Mo	Fe	Cu	S	Co
0.10-0.40	15.0-16.50	≤0.5	≤0.1	<0.01	<0.20

Typical Welding Parameters
Diameter		Process	Volt	Amps (flat)	Amps (V/OH)
inch	(mm)	Process	Volt	Amps (flat)	Amps (V/OH)
0.035	0.9	GMAW	26-29	150-190	Spray Transfer 100% Argon
0.045	1.2	GMAW	28-32	180-220	Spray Transfer 100% Argon
1/16	1.6	GMAW	29-33	200-250	Spray Transfer 100% Argon
1/16	1.6	GTAW	14-18	90-130	100% Argon
3/32	2.4	GTAW	15-20	120-175	100% Argon
1/8	3.17	GTAW	15-20	150-220	100% Argon

Tensile Strength	109 Ksi	790 MPA
Yield Strength	68 Ksi	470 MPA
Elongation	40-45%
Density g/cm3	8.60 g/cm3
Melting Point ℃	1300-1360℃
Coefficient of Expansion. 21-93 Co, μm/m * Co	11.90

Item	ERNiCrMo-3	ERNiCrMo-4	ERNiCrMo-13	ERNiCrFe-7	ERNiCr-3	ERNiCu-7	ERCuNi	ERNi-1
C	0.1	0.02	0.01	0.04	0.1	0.15	0.03	0.15
Mn	0.05	1	0.5	1	2.5-3.5	4	0.5-1.0	1
Fe	5	4-7	1.5	7-11	3	2.5	0.65	1
P	0.02	0.04	0.015	0.02	0.03	0.02	0.01	0.03
S	0.015	0.03	0.005	0.015	0.015	0.015	0.01	0.015
Si	0.05	0.08	0.1	0.5	0.5	1.25	0.15	0.75
Cu	0.5	0.5	N/A	0.3	0.5	rest	rest	0.25
Ni	≥58	rest	rest	rest	≥67	62-69	30-32	≥93
Co	N/A	2.5	0.3	N/A	N/A	N/A	N/A	N/A
Al	0.4	N/A	0.1-0.4	1.1	N/A	1.25	0.15	1.5
Ti	0.4	N/A	N/A	1	0.75	1.5-3	0.5	2-3.5
Cr	20-23	14.5-16.5	22-24	28.5-31	18.0-22.0	N/A	N/A	N/A
Nb+Ta	3.5-4.15	N/A	1.8-2.5	0.01	2.0-3.0	N/A	N/A	N/A
Mo	8.0-10	15-17	15-16	0.5	N/A	N/A	N/A	N/A
V	N/A	0.35	N/A	N/A	N/A	N/A	N/A	N/A
W	N/A	3.-4.5	N/A	N/A	N/A	N/A	N/A	N/A
Rest	≤0.50	≤0.50	≤0.50	≤0.50	≤0.50	≤0.50	≤0.50	≤0.50

Nickel Alloy 625 600 601 Inconel Welding Wire Ernicrmo-3/Ernicr-3
