    Nuclear Energy N08800 Incoloy 800 Wire Incoloy Alloy Wire With High Temperature Resistance

    Ask Lasest Price
    Brand Name : Victory
    Model Number : Incoloy 800
    Certification : CE,ROHS,ISO 9001
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 300 tons per month
    Delivery Time : 5-21 days
    • Product Details
    • Company Profile

    Nuclear Energy N08800 Incoloy 800 Wire Incoloy Alloy Wire With High Temperature Resistance

    Introduction:


    Incoloy 800 alloy wire is a high-temperature alloy material that is widely used in the nuclear energy industry. It is composed of various elements such as nickel, iron and chromium. It has excellent heat resistance, corrosion resistance and high strength. It is suitable for key components of nuclear energy equipment and the thermal environment of nuclear reactors.


    In the field of nuclear energy, the heat resistance of Incoloy 800 alloy wire is one of its distinctive features. There are extreme high-temperature environments in nuclear reactors. The heat generated by nuclear fuel and high-temperature coolant place stringent requirements on materials. Incoloy 800 alloy wire can work stably for a long time under high temperature conditions and has good high temperature strength and thermal stability to ensure the safe operation of nuclear energy equipment.


    Incoloy 800 alloy wire plays an important role in the field of nuclear energy and is widely used in key components of nuclear reactors, nuclear power plants and other nuclear energy equipment. Its heat resistance, corrosion resistance and high strength ensure the efficient operation and safety of nuclear energy equipment and make important contributions to the development of the nuclear energy industry.



    Parameter:


    Main ingredients: nickel (30-35%), iron (39.5% minimum content), chromium (19-23%), copper (0.75% maximum content), aluminum (0.15-0.60%), carbon (0.1% maximum content)
    Density: 7.94 g/cm3
    Melting point: 1350-1400 degrees Celsius
    Yield strength: ≥240 MPa
    Tensile strength: ≥600 MPa
    Thermal expansion coefficient: 13.9 x 10^-6/degrees Celsius (range 20-100 degrees Celsius)


    IncoloyNiCrFeCMnSSiCuAlTi
    80030.0-35.019.0-23.039.5min0.10max.1.50max.0.015max.1.0max.0.75max.0.15-0.600.15-0.60

    AMS NumberAlloyTypeUNSCross Ref. SpecMisc./Shape
    AMS 5766 BarIncoloy 800NickelN08800-Bar
    AMS 5766 Custom TubeIncoloy 800NickelN08800-Custom Tube
    AMS 5871 PlateIncoloy 800NickelN08800-Plate
    AMS 5871 SheetIncoloy 800NickelN08800-Sheet
    AMS 5871 StripIncoloy 800NickelN08800-Strip
    Shape
    Size(mm)
    Wire
    0.5-7.5
    Rod/Bar
    8.0-200
    Strip
    (0.5-2.5)*(5-180)
    Tube
    custom made
    Plate
    custom made

    Characteristic:


    • Corrosion resistance: Incoloy 800 alloy wire shows excellent corrosion resistance in the nuclear energy field and can resist the erosion of acidic, alkaline and oxidizing media, extending the service life of equipment.
    • High temperature stability: This alloy wire has excellent high temperature stability and oxidation resistance, and can maintain the stability and strength of its structure under high temperature and irradiation conditions.
    • Radiation Resistance: Incoloy 800 alloy wire has good resistance to radiation and can withstand the challenges of radiation environments in nuclear energy equipment.

    Advantage:


    • Nuclear energy applications: Incoloy 800 alloy wire is often used in nuclear reactors in the nuclear energy field to manufacture fuel elements, heat exchangers and other nuclear equipment. It can ensure the safe operation of equipment in high temperature, corrosion and radiation environments.
    • Anti-oxidation properties: This alloy wire contains a high proportion of nickel and chromium, which gives it good anti-oxidation properties and can resist high-temperature oxidation reactions and protect equipment from oxidative damage.
    • High strength characteristics: Incoloy 800 alloy wire has high yield strength and tensile strength, and can withstand extreme working conditions such as high temperature, high pressure and radiation in nuclear energy equipment.

    Specific applications:


    1. Fuel elements: Incoloy 800 alloy wire is widely used in the manufacture of fuel elements for nuclear reactors to wrap and protect nuclear fuel. It also has good corrosion resistance and radiation resistance.
    2. Heat exchanger: This alloy wire is often used in the manufacture of nuclear energy heat exchangers to transfer heat and maintain the stability of the equipment. It has the characteristics of high temperature resistance, corrosion resistance and radiation resistance.

    Related knowledge points:


    Incoloy 800 alloy wire has good weldability and can be connected to other materials through different welding methods.

    The application of this alloy wire in the nuclear energy field requires compliance with strict standards and specifications to ensure the safety and reliability of the equipment.

    The use of Incoloy 800 alloy wire in nuclear energy equipment requires consideration of the impact of the radiation environment on material properties, as well as radiation protection measures during the design and manufacturing process.



    Q & A:


    Q: Does Incoloy 800 Wire meet industry quality standards?
    A: Yes, Incoloy 800 Wire is manufactured to meet rigorous industry quality standards. It undergoes strict quality control measures throughout the production process to ensure consistency, performance, and adherence to specifications.

    Q: What are the quality assurance measures for Incoloy 800 Wire?
    A: Incoloy 800 Wire often tested for factors such as chemical composition, tensile strength, corrosion resistance, and dimensional accuracy to ensure high-quality and reliable performance.
