Introduction:
Inconel 601 alloy wire is a nickel-chromium alloy that contains a
high proportion of nickel and chromium, as well as added elements
such as aluminum and titanium. These elements give Inconel 601
alloy wire excellent high temperature corrosion resistance and heat
resistance. It is usually supplied in wire form and can be used to
manufacture critical components in heat treatment equipment.
In heat treatment equipment, Inconel 601 alloy wire is often used
to manufacture key components such as furnaces, furnace tubes,
heating elements and protective sleeves. It can maintain stable
mechanical properties and anti-oxidation properties in high
temperature environments, and can resist corrosion and oxidation at
high temperatures.
Characteristic:
- High temperature resistance: Inconel 601 alloy wire has excellent
high temperature resistance and can operate stably for a long time
in high temperature environments. It is able to withstand stress
and thermal cycling at high temperatures and maintain good
mechanical properties.
- Corrosion resistance: Inconel 601 alloy wire has good corrosion
resistance to a variety of corrosive media. It can resist corrosion
from corrosive media such as high-temperature oxidizing atmosphere,
sulfuric acid, nitric acid, alkali solutions and molten salts,
thereby extending the service life of the equipment.
- Oxidation resistance: Inconel 601 alloy wire forms a dense oxide
film at high temperatures, which can provide effective
anti-oxidation protection. This oxide film can prevent oxidation
and corrosion of materials and maintain the stability and
performance of the alloy wire.
Advantage:
- High temperature corrosion resistance: Inconel 601 alloy wire is an
alloy material specially designed for high temperature environments
and has excellent high temperature corrosion resistance. It can
maintain stable performance at high temperatures and is not
susceptible to oxidation, corrosion and high temperature atmosphere
erosion.
- Good mechanical properties: Inconel 601 alloy wire has good
high-temperature strength and resistance to stress corrosion
cracking, and can withstand stress and thermal cycles at high
temperatures. It also has good plasticity and processability,
making it easy to manufacture and process into various shapes and
sizes.
- Corrosion resistance to a variety of corrosive media: Inconel 601
alloy wire has good corrosion resistance to a variety of corrosive
media, including high-temperature oxidizing atmospheres, sulfuric
acid, nitric acid, alkali solutions and molten salts. This makes it
an ideal material for heat treatment equipment handling corrosive
gases or liquids.
Specific applications:
- Furnace and furnace tubes: Inconel 601 alloy wire is often used to
manufacture furnace hearths and furnace tubes for high-temperature
heat treatment equipment. It can withstand the requirements of
high-temperature environments and thermal cycles, maintaining
structural stability and performance.
- Heating elements: Inconel 601 alloy wire can be used to make
heating elements, such as resistance wires and electric heating
plates. These heating elements provide high-temperature heating and
are suitable for a variety of heat treatment processes.
- Protective casing: Inconel 601 alloy wire can be used as protective
casing in heat treatment equipment. It protects internal components
from corrosion and high temperature erosion, improving the
reliability and life of the equipment.
In summary, Inconel 601 alloy wire has excellent high temperature
corrosion resistance, heat resistance and corrosion resistance in
heat treatment equipment. It can withstand stress and thermal
cycles in high temperature environments and has good corrosion
resistance to a variety of corrosive media. Therefore, it is widely
used in the manufacture of heat treatment equipment such as
furnaces, furnace tubes, heating elements and protective sleeves.
Parameter:
Chemical composition:
Nickel (Ni): about 61%
Chromium (Cr): about 23%
Aluminum (Al): about 1.4%
Titanium (Ti): about 0.1%
Density: approximately 8.11 g/cm³
Melting point: approximately 1,370-1,415°C
Tensile strength: At room temperature, the tensile strength of
Inconel 601 alloy wire is typically 550 MPa (Megapascals).
Yield strength: At room temperature, the yield strength of Inconel
601 alloy wire is typically 220 MPa.
Thermal expansion coefficient: In the range of degrees Celsius, the
linear expansion coefficient of Inconel 601 alloy wire is
approximately 13.1×10^-6/°C.
Thermal conductivity: The thermal conductivity of Inconel 601 alloy
wire is approximately 9.9 W/(m·K) in the Celsius range.
Magnetic properties: Inconel 601 alloy wire is non-magnetic.
| Item | C | Mn | Fe | P | S | Si | Cu | Ni | Co | Al | Ti | Cr | Nb+Ta | Mo | B |
Inconel 601 | ≤0.1 | ≤1.5 | rest | ≤0.02 | ≤0.015 | ≤0.5 | ≤1 | 58-63 | -- | 1-1.7 | -- | 21-25 | -- | -- | -- |
| AMS Number | Alloy | Type | UNS | Cross Ref. Spec | Misc./Shape |
|---|
| AMS 5715 | Inconel 601 | Nickel | N06601 | |
| AMS 5715 Bar | Inconel 601 | Nickel | N06601 | - | Bar |
| AMS 5715 Custom Tube | Inconel 601 | Nickel | N06601 | - | Custom Tube |
| AMS 5715 Forging | Inconel 601 | Nickel | N06601 | - | Forging |
| AMS 5715 Ring | Inconel 601 | Nickel | N06601 | - | Ring |
| AMS 5870 | Inconel 601 | Nickel | N06601 | |
| AMS 5870 Plate | Inconel 601 | Nickel | N06601 | - | Plate |
| AMS 5870 Sheet | Inconel 601 | Nickel | N06601 | - | Sheet |
| AMS 5870 Strip | Inconel 601 | Nickel | N06601 | - | Strip |
contact us
email:victory@dlx-alloy.com
Oem service:
Welcome customized size
We are experience factory for OEM&ODM service
Q & A:
Q1: What are the typical applications of Inconel 601 wire?
A1: Inconel 601 wire is commonly used in aerospace, chemical
processing, and high-temperature applications.
Q2: What are the advantages of using Inconel 601 wire compared to
other alloys?
A2: Inconel 601 wire offers excellent heat and corrosion
resistance, making it a preferred choice in demanding environments.
